BRAVO 40 | 40 Amp MPPT Solar Charge Controller | Premium 40A 12V/24V MPPT Solar Controller for RVs, Trailers, Campers, Vans, Boats, Off-Grid | Awarded #1 Solar Controller 2025

$111.99

Supercharge your solar setup with elite power management. Specifically, the Bravo 40 is a top 40 amp mppt solar charge controller engineered to squeeze every drop of energy from your panels. However, using old PWM controllers can waste up to 30% of your total solar generation. Fortunately, this premium 40a mppt solar controller tracks the maximum power point in real time. Consequently, it boosts your charging efficiency even on dark, cloudy days. Therefore, it delivers a faster, safer charge directly to your 12V or 24V battery bank. As a result, it is the perfect component upgrade for custom van builds,…

SKU: RS-MPPT40P
Category: ,
Tags: , , , , , , , , , , , , ,
Brands:

Description

Features

  • MPPT
  • Tracking Efficiency Above 99.5%
  • Charge Conversion Efficiency as high as 98%
  • 12V/24V DC System Self-Adaptation
  • Reverse Discharge Protection
  • Targeted for Accuracy
  • Overvoltage Protection
  • Common Negative Connection
  • Charging Data Storage
  • Conformal Coating For Inside Board
  • In-house Design And Manufacture
  • Extensive Internal Electronics, In-Circuit Protections, And Safety Protections
  • Targeted For Lead Acid Batteries: Gel, AGM, WET, CRYSTAL, CALCIUM Batteries Type Selections
  • Targeted For Lithium Batteries: LiFePO4, LTO (Lithium Titanium Oxide), LCO Batteries Type Selections

Specifications

  • System Nominal Voltage: 12/24V Auto
  • Max. PV Open Circuit Voltage: 100V DC
  • Charging Technology: MPPT
  • Max PV Charging Current: 40A
  • Max. Recommended PV Input Power: 600 Watt (12V) / 1200 Watt (24V)
  • Charge Conversion Efficiency: ≤98%
  • MPPT Tracking Efficiency: >99.5%
  • Battery Type Preset: Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
  • Housing Case Color: Black / Grey
  • IP Grade: IP43 for Inside PCBA, IP22 for Connection Area
  • Net Weight: 1.17kg / 2.58lb
  • Dimensions (L*W*H): 195*142*74 mm / 7.7*5.5*2.9 in
